Physical Parameters

Type of LED Black 3in1 SMD
Pixel (mm) 2.97
Dimension of cabinet (WxHxD)/(mm) 500x500x88
Pixel per cabinet 168x168
Weight of cabinet (kg) 7.6
Cabinet material Casting of aluminum
Module dimensions (LxA) / (mm) 250×250

Parameters Optoelectronics

Brightness 1000 cd/㎡
Update rate (Hz) 3840
Grey scale (bit) 14
Contrast 5500:1
Color temperature 6500
Angle of eyesight: (H / V) (°) 140/140

Receiving Card A8S

input voltage CC 3,3 V–5,5 V
nominal current 0,5 A
rated power consumption 2,5 W
temperature -20°C–+70°C
humidity 10% UR–90% UR, sem condensação
tempeture -25°C–+125°C
certifications RoHS, EMC Classe B

Parameter Application

Temperature storage (℃) - 20 ~ + 50
Operating Temperature (℃) - 10 ~ + 40 Storage
Humidity (RH) 10% ~ 90%
Humidity operation (RH) 10% ~ 90%
IP Rating (Front /Rear) IP40 / IP21
LED life (H) 100000
Maintenance module RPSU and other
Maintenance R
Type of Installation Panel Rigging / Stuck, Rear Installation
Perforation (vertical) (PCS) 40

Driving Type 1/28
AC Operation (V) 100~240
Power Consumption (Max./Avg.)(W / m²) 540/180
