Physical Parameters

LED type: Outdoor SMD
Pixel pitch (mm): 3.9
Panel dimensions (W×H×D) (mm): 1000 × 500 × 78.5
Pixels per panel: 256 × 64
Panel weight (kg): 7.3
Panel material: Die-cast aluminum
Module dimensions (W×H) (mm): 500 × 125
Front and rear maintenance

Optoelectronic Parameters

Brightness (nits): 4000
Transparency: 49%
Permeability: 55%
Refresh rate (Hz): 7680
Contrast ratio: 7000:1
Color temperature (K): 7500
Viewing angle (H/V) (°): 140 / 100
Driving type: 1/16
Operating voltage AC (V): 200 ~ 240 (or 100 ~ 120)
Power consumption (Max./Avg.) (W/m²): 600 / 300
