Physical Parameters

LED type: Black SMD
Pixel pitch (mm): 3.9
Panel dimensions (W×H×D) (mm): 500 × 1000 × 79
Pixels per panel: 128 × 128 / 128 × 256
Panel weight (kg): 13.5
Panel material: Die-cast aluminum
Module dimensions (W×H) (mm): 250 × 250

Optoelectronic Parameters

Brightness (nits): 4000
Refresh rate (Hz): 1920
Grayscale (bit): 16
Contrast ratio: 5000:1
Color temperature (K): 3000 ~ 10000
Viewing angle (H/V) (°): 160 / 140
Driving type: 1/16
Operating voltage AC (V): 200 ~ 240 (or 100 ~ 120)
Power consumption (Max./Avg.) (W/m²): 600 / 200
